Renesas Electronics Triac-Based Motor Controller
Renesas Electronics Triac-Based Motor Controller provides a robust, compact air conditioning system for small-scale applications including vehicle systems. This system is based on triacs to simplify the design as compared to inverter-based designs. The controller features the RX231 32-bit microcontroller (MCU) or the ARM® processor-based RA2E1 32-bit MCU to enable efficient design.
Features
- Optimized Triac control for a simplified compressor motor control system design
- RX231 low power, high-performance 32-bit microcontroller (MCU) or ultra-low power widely used ARM® processor-based RA2E1 32-bit MCU to enable efficient design
- RAA223021 high voltage AC/DC buck regulator to convert the rectified AC power going to the system, allowing for simple operation
- Enhanced system monitoring for fail-safe protection, sensing current and load
Applications
- AC powered motor control
- Portable air conditioners
- Recreational vehicle air conditioners
Block Diagram
FEATURED PRODUCTS
Renesas Electronics RX23E-A MCUs
32MHz and 32-bit RX MCUs with built-in FPU and up to 256KB flash.
Renesas Electronics RA2E1 48 MHz ARM Cortex®-M23 MCU
RA Ailesinde 48 MHz Arm ® Cortex®-M23 çekirdeğine dayanan giriş seviyesi MCU.
Renesas Electronics RAA223021 700V Non-Isolated AC-DC Buck Regulator
700V AC-DC buck regulator with ultra-low standby power and up to 8.0W output power.
Renesas Electronics ISL32704E Isolated RS-485 Transceivers
Designed for 4Mbps bidirectional data transmission for Industrial Internet of Things networks.
